品牌Brand

苏华特SUHUATE

型号Type

SHT2412

电器 系 统

Electrical system

电控Electric control

大六管无线控制器Six - transistor Wireless Controller

电池Battery

48V20Ah,天能/超威品牌铅酸电池48V20Ah Tianneng/Chilwee Brand Lead - acid Battery

电机Motor

安乃达400W高效节能电机Ananda 400W High - efficiency and Energy - saving Motor

电路系统Circuit system

全车防水接插件，分体式电源Full-vehicle waterproof connectors, with split-type power supply.

充电器Charger

48V 充电平稳、耐高温With 48V, the charging process is stable and it can withstand high temperatures.

充电时间Charging time

6-8 小时 6-8 hours

音响Audio system

电喇叭Electric horn

车身 配 置

Body matching

车体Body

钢制车架+塑料外壳 Steel frame + plastic shell

仪表台Dashboard

多功能液晶数码仪表盘，功能齐全Dashboard: Multi - function LCD digital instrument panel with complete functions.

车架Frame

微型车车架，高强度钢结构件.The frame is of a micro-car type, made of high-strength steel structural parts.

灯光及信号

Lights and signals

LED大灯，前后带转向灯 LED headlight with front and rear turn signals

颜色Color

红色标准色，客户可定制Standard red color, customizable by customers.

座椅Seat

770mm整体式海绵外包皮革座椅 ，舒适耐用。Seat: 770mmIntegrated sponge seat covered with leather, which is comfortable and durable.

底盘

Bottom plate

动力传动系统Power transmission system

无级调速系统Stepless speed control system

驱动系统Drive system

后轴驱动Rear axle drive

减震Shock absorption

精品后减震High - quality rear shock absorption

制动系统Brake system

前后110mm鼓刹 Front and rear 110mm drum brakes

外形尺寸长*宽*高(mm)

Size Length * Width * Height (mm)

1560×660×1070 mm

轴距Wheelbase

1460 mm

轮胎Tyre

14×2.5 真空轮胎，铁轮 14×2.5 vacuum tire, iron wheel

整车装备质量

Vehicle curb weight

63kg

整车载荷

Vehicle load-carrying capacity

100kg

制动距离

Braking distance

≤6.5 m

座额定乘员Rated passenger capacity

2 人（含驾驶员）2 persons (including the driver).

初速30km/h 制动距离

Braking distance at an initial speed of 30km/h

≤6.5 m

最大行驶速度

Maximum travel speed

三档变速，最高时速43km/h

Three - speed transmission, maximum speed 43 km/h

续驶里程Range

≤ 65 Km

最大爬坡度

Maximum gradient

≤ 20%

充电输入电压

Charge input voltage

220v
