品牌Brand

苏华特SUHUATE

型号Type

SHT2572

电器 系 统

Electrical system

电控Electric control

72V通用电压，3000W专用大功率控制器，ANANDA12寸3000W电机，72V universal voltage, 3000W dedicated high-power controller, ANANDA 12-inch 3000W motor

电池Battery

72V50Ah三元锂电池72V50Ah ternary lithium battery

电机Motor

ANANANDA12寸3000W永磁直流无刷电机ANANANDA 12-inch 3000W permanent magnet DC brushless motor

电路系统Circuit system

全车防水接插件，分体式电源Full-vehicle waterproof connectors, with split-type power supply.

充电器Charger

72V锂电充电器，耐用、安全、充电平稳、耐高温72Vlithium charger, durable, safe, stable charging, high temperature resistance

充电时间Charging time

6-8小时 6-8 hours

车身 配 置

Body matching

车体Body

钢制车架+塑料外壳 Steel frame + plastic shell

仪表Instrument panel

超高亮液晶仪表，可选配蓝牙音响，NFC功能，CARPLAY系统Ultra-bright LCD instrument, optional Bluetooth speaker, NFC function and CARPLAY system

车架Frame

锂电、铅酸通用车架，高强度钢结构件；整车采用大踏板，前后避震，结构硬朗、扎实、稳定。Lithium battery, lead-acid general frame, high-strength steel structure; The whole vehicle adopts large pedal, front and rear shock absorber, the structure is strong, solid and stable.

前叉Front fork

杆套结构，无缝钢管，锻打实心方向器，提高整车安全性Rod sleeve structure, seamless steel pipe, forged solid steering device, improving the overall safety of the vehicle.

灯光及信号Lights and signals

全车LED灯具，灯光透射力强Full-vehicle LED lighting with strong light transmittance

遥控器及防盗器Remote control unit and burglar alarm

双遥控报警器Dual remote control alarm

前减震Front shock absorber

杆套型全油压减震Rod sleeve type full hydraulic shock absorption

后减震Rear shock absorber

双管阻尼后减震Dual-tube damping rear shock absorption

鞍座Saddle

加厚海绵Thickened sponge

底盘

Bottom plate

动力传动系统Power transmission system

大功率玄波控制器+大功率防水直流永磁无刷电机High-power sine wave controller + high-power waterproof DC permanent magnet brushless motor

驱动系统Drive system

后轴驱动Rear axle drive

制动系统Brake system

前后碟刹，陶瓷刹块Front and rear disc brakes, ceramic brake blocks

外形尺寸长*宽*高(mm)

Size Length * Width * Height (mm)

2050mm×520mm×1170

轴距Wheelbase

1350mm

轮胎Tyre

TIMSUN120/70/12高抓轮胎

TIMSUN 120/70/12 high-grip tire

制动距离Braking distance

≤6.5 m

最大行驶速度Maximum travel speed

≤80km/h

续驶里程Range

≤110Km

最大爬坡度Maximum gradient

≤30°

充电输入电压Charge input voltage

220v
