品牌Brand

苏华特Suhuate

型号Type

SHT2561

电器系统

Electrical system

电控Electric control

72V通用电压，4000W专用大功率控制器，ANANDA12寸4000W电机，72V universal voltage, 4000W dedicated high-power controller, ANANDA 12-inch 4000W motor

电池Battery

72V50Ah三元锂电池72V50Ah ternary lithium battery

电机Motor

ANANANDA12寸4000W永磁直流无刷电机

ANANDA 12-inch 4000W permanent magnet DC brushless motor

电路系统Circuit system

全车防水、阻燃插件，骑行更安全Whole waterproof, flame retardant plug-in, more safe riding

充电器

Charger

依据客户电池容量设定Set according to the customer's battery capacity

充电时间Charging time

6-8小时

车身配置

Body matching

车体Body

钢制车架+塑料外壳Steel frame + plastic shell

仪表Instrument panel

超高亮液晶仪表，可选配蓝牙音响，NFC功能Ultra-bright LCD instrument, optional Bluetooth speaker and NFC function

车架Frame

Q193

前叉Front fork

杆套结构，无缝钢管，锻打实心方向器，提高整车安全性Rod sleeve structure, seamless steel pipe, forged solid direction indicator, improving the overall safety of the vehicle

灯光及信号Lights and signals

全车LED灯具，灯光透射力强

Full-vehicle LED lighting with strong light transmittance

遥控器及防盗器Remote control unit and burglar alarm

双遥控报警器或租赁专用IOTDual remote control alarm or rental-specific IOT

前减震Front shock absorber

杆套型全油压减震Rod sleeve type full hydraulic shock absorption

底盘

Bottom plate

后减震Rear shock absorber

阻尼后减震，提高舒适度Damping rear shock absorption to improve comfort

动力传动系统

Power transmission system

大功率玄波控制器+大功率防水直流永磁无刷电机High-power sine wave controller + high-power waterproof DC permanent magnet brushless motor

驱动系统Drive system

后轴驱动，最大负载可达400kg

Rear axle drive, maximum load up to 400kg

制动系统Brake system

前后碟刹，陶瓷刹块Front and rear disc brakes with ceramic brake pads

轮胎Tyre

TIMSUM120/70/12半热熔轮胎TIMSUM 120/70/12 Semi - Slick Tire

外形尺寸长*宽*高(mm) Size Length * Width * Height (mm)

2200×510×1170mm

整车装备质量

Vehicle curb weight

96kg

整车载荷

Vehicle load-carrying capacity

≤300kg

轴距Wheelbase

1400mm

制动距离Braking distance

≤6.5 m

续驶里程Range

≤100Km

最大爬坡度Maximum gradient

≤30°

最大行驶速度Maximum travel speed

≤90km/h

充电输入电压

Charge input voltage

220v
