品牌Brand

苏华特SUHUATE

型号Type

SHT586

电器 系 统

Electrical system

电控Electric control

72V通用电压，3000W专用大功率控制器，ANANDA12寸3000W电机，60-72V universal voltage, 3000W dedicated high-power controller, ANANDA 12-inch 3000W motor

电池Battery

72V50Ah三元锂电池72V50Ah ternary lithium battery

电机Motor

ANANANDA12寸3000W永磁直流无刷电机ANANDA 12-inch 3000W permanent magnet DC brushless motor

电路系统Circuit system

全车防水接插件，分体式电源Full vehicle waterproof connectors, split power supply

充电器Charger

72V 充电平稳、耐高温With 72V, the charging process is stable and it can withstand high temperatures.

充电时间Charging time

6-8小时 6-8hours

车身 配 置

Body matching

车体Body

钢制车架+塑料外壳 Steel frame + plastic shell

仪表Instrument panel

超高亮液晶仪表，可选配蓝牙音响，NFC功能Ultra-bright LCD instrument, optional Bluetooth speaker and NFC function

车架Frame

微型车车架，高强度钢结构件.The frame is of a micro-car type, made of high-strength steel structural parts.

前叉Front fork

杆套结构，无缝钢管，锻打实心方向器，提高整车安全性

• 杆套结构：Bushing structure

• 无缝钢管：Seamless steel pipe

• 锻打实心方向器：Forged solid steering device，

• 提升整车安全性（improves overall vehicle safety）

灯光及信号Lights and signals

全车LED灯具，灯光透射力强Full-vehicle LED lighting fixtures with strong light transmission

遥控器及防盗器Remote control unit and burglar alarm

双遥控报警器Dual remote control alarm

前减震Front shock absorber

杆套型全油压减震

Rod - bushing type full - oil - pressure shock absorber

后减震Rear shock absorber

双管阻尼后减震

Double - tube damping rear shock absorber

鞍座Saddle

加厚海绵提高舒适度Thickened sponge to improve comfort

底盘

Bottom plate

动力传动系统Power transmission system

大功率玄波控制器+大功率防水直流永磁无刷电机High - power sine - wave controller + high - power waterproof permanent - magnet brushless DC motor

驱动系统Drive system

后轴驱动Rear axle drive

制动系统Brake system

前后碟刹，陶瓷刹块

Front and rear disc brakes, ceramic brake blocks

外形尺寸长*宽*高(mm)

Size Length * Width * Height (mm)

2050mm×510mm×1170

整车装备质量Vehicle curb weight

96kg

整车载荷Vehicle load-carrying capacity

200kg

轴距Wheelbase

1340mm

轮胎Tyre

90/80/12半热熔轮胎

90/80/12 semi-hot melt tire

初速30km/h 制动距离 Braking distance at an initial speed of 30km/h

≤6.5 m

最大行驶速度Maximum travel speed

≤80km/h

续驶里程Range

≤100Km

最大爬坡度Maximum gradient

≤30°

充电输入电压Charge input voltage

220v
