品牌Brand

苏华特SUHUATE

型号Type

SHT2471（原2451，2025.11.8改为2471）

电器 系 统

Electrical system

电控Electric control

72V 智能化控制系统；无级调速 ，制动断电 ，欠压保护 ，过 流保护等性能 ，稳定。72V 12 管 控制器 ，强劲快速。72V intelligent control system; It has stable performance features such as stepless speed regulation, power cut-off during braking,under-voltage protection, over-current protection, etc. A 72V 12-tube controller provides strong and rapid performance.

电池Battery

72V 40Ah 三元锂电池72V 40Ah Ternary lithium battery

电机Motor

72V 1000W 电机；超大功率满盘电机 ，动力持久强劲， 爬坡能力 ，载重能力强。72V 1000W motor; It is a super high-power full-disc motor, offering lasting and powerful performance, with strong climbing ability and high load-bearing capacity.

音响Audio system

电喇叭Electric horn

充电器Charger

72V 充电平稳、耐高温With 72V, the charging process is stable and it can withstand high temperatures.

充电时间Charging time

6-8 小时 6-8hours

车身 配 置

Body matching

颜色Color

高级灰色标准色，客户可定制Color:Advanced gray standard color, which can be customized by customers.

车体Body

钢制车架+塑料外壳 Steel frame + plastic shell

仪表台Dashboard

多功能液晶数码仪表盘，功能齐全Dashboard: Multi - function LCD digital instrument panel with complete functions.

车架Frame

微型车车架，高强度钢结构件.The frame is of a micro-car type, made of high-strength steel structural parts.

灯光及信号Lights and signals

前照灯 ，前后转向灯 ，组合后尾灯 ，电喇叭；凌厉霸气的水 晶的前大灯 ，按照仿生学原理设计 ，外形更美观 ，照明更安 全Headlights, front and rear turn signals, combined rear taillights, and an electric horn. The sharp and imposing crystal headlights are designed in accordance with the principles of bionics, featuring a more aesthetically pleasing appearance and ensuring safer illumination.

后视镜Rearview mirrors

左右各一手动型外后视镜Rearview mirrors: One manual external rearview mirror on each of the left and right sides.

座椅Seat

整体式海绵外包皮革座椅，舒适耐用。Seat: Integrated sponge seat covered with leather, which is comfortable and durable.

底盘

Bottom plate

动力传动系统Power transmission system

无级调速系统Stepless speed control system

驱动系统Drive system

后轴驱动Rear axle drive

制动系统Brake system

前碟刹,后碟刹 ，性能优越Front disc brake, rear disc brake, superior performance.

外形尺寸长*宽*高(mm)

Size Length * Width * Height (mm)

1998×490× 1100 mm

整车装备质量Vehicle curb weight

86kg

整车载荷Vehicle load-carrying capacity

200kg

轴距Wheelbase

1460 mm

轮胎Tyre

前轮：3.0-12 后轮3.0-10 ，耐磨防刺穿 ，品牌真空轮胎Front tire: 3.0-12 Rear tire: 3.0-10 Wear-resistant and puncture-proofBrand vacuum tire

额定乘员Rated passenger capacity

2 人（含驾驶员） 2 persons (including the driver).

初速30km/h 制动距离 Braking distance at an initial speed of 30km/h

≤6.5 m

最大行驶速度Maximum travel speed

≤50km/h

续驶里程Range

≤100Km

最大爬坡度Maximum gradient

≤20°

充电输入电压Charge input voltage

220v

智能中控Smart central control

智能中控对接租赁Smart central control docking leasing
